SPECIFICATIONS

Principle	Zirconia electro-chemical cell
Structure	SS box, TB-IIP sensor, C-101 control unit, needle valve, flow meter etc.
Model	TB-FI	Pressurized sample
	TB-FI-P	Sampling pump installed
	TB-FI-PC	Sampling pump and charcoal filter installed
	TB-FI-PR	Sampling pump and charcoal filter and mist-separator installed
Measuring range	1ppm~100％O2
Display	％:0~99.99％O2 ppm:0～9999ppmO2
Output	D.C.4~20mA, 0~1V or 0~10V（isolated） F.S. can be set within the range of the above-mentioned display freely. RS232C
Range change	Auto/Manual
Initial setting	0~25％O2/0~1000ppmO2
Alarm	Output :Hi/Lo, HHi/Hi or Lo/LLo（each Ａ Point of contact・LCD Display） Failure：Disconnection of Heater, RTD（LCD Display）
Linearity	Large one either of less than ±1％FS or±1ppm
Repeatability	Large one either of less than ±1％FS or±1ppm
Response	90% reading 10sec.（Swinging to a high density side）
Drift	Less than ±2％FS/wk
Piping	Rc1/4
Sample Flow Rate	0.2~2L/min
Sample Temp.	300°C MAX.
Sample pressure	Others　203kPa~1.33×10-1Pa（2atm~10-3Torr）
Warm up time	About 20 minutes
AC Power	AC85V~AC260V
Accessory	Power supply code
