| Construction |
A platinum band is wound
onto a solid glass core and homogeneously fused with the
exterior glass. The lead wire connection is shear force
resistant. |
| Nominal resistance value |
100
ohms at 0°C |
| Tolerance class |
A and B according to DIN IEC
751. Narrower tolerance in restricted temperature ranges. |
| Temperature range |
-200
°C to +400 °C |
| Temperature stability |
Extremely long-time stable;
drift after many years in use is possible |
| Vibration resistance |
Very high resistance to
vibration and shock |
| Mechanical stability |
Insensitive to external
forces and pressure |
| Environmental conditions |
Unhoused suitable for
aqueous and organic liquids |
| Further special
features |
- Small size
- Easy modification according to customer demands
- Connection wires are extremely well protected
against being torn off
- Very abrasive resistant
|
